Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
TP400 Series Thermal Pad
TP400 elevates the thermal performance bar, achieving 4.0W/m.K while maintaining a hardness of 55 (shore 00). The low hardness in comparison to thermal conductivity proves that TP400 will meet the demands of your challenging design requirements.
Features: thermal conductivity: 4.0W/m.K, low silicone oil extraction.
Applications: LED lighting systems, power supplies and conversion, semiconductor packaging, IGBTs, automotive, wireless charging, advanced driver assistance systems (ADAS), battery control units (BCUs) .
Send Inquiry
Applications: LED lighting systems, power supplies and conversion, semiconductor packaging, IGBTs, automotive, wireless charging, advanced driver assistance systems (ADAS), battery control units (BCUs) .
Technical Information
Attribute |
Value |
Test Method |
| Composition | Ceramic Filler + Silicone | - |
| Color | Purple | Visual |
| Thickness (mm) | 0.5 ~ 10.0 | ASTM D374 |
| Density (g/cc) | 3.1 | ASTM D792 |
|
Hardness (shore oo) |
55 (Thickness ≤ 1.0 Shore OO 60) | ASTM D2240 |
| Usage Temperature (℃) | -60 ~ +200 | - |
Electrical |
||
| Breakdown Voltage (kV/mm) | ＞6.0 | ASTM D149 |
| Dielectric Constant | ＜7.5 | ASTM D150 |
| Volume Resistivity (Ω.cm) | 1013 | ASTM D257 |
| Flammability | V-0 | UL 94 |
Thermal |
||
| Thermal Conductivity (W/m.K) | 4.0 | ISO 22007-2 |
Legal Disclaimer
The technical information and data shown on this page should be considered representative or typical only and should not be used for specification purposes. Please contact us or e-mail sales@aok-technologies.com to determine product availability.
* OEM: thermal pads are available in sheets or cut parts to match a wide range of industry standard or customer defined outlines.
Thermal Pad Manufacturer
AOK
Standard Sheet Size
200x400mm or custom die cut parts.
Thickness available in 0.25mm increments.
Storage
Store in a cool, dry, well-ventilated place.
Shelf life
Shelf life of the product is 12 months after date of shipment.
