TG200-S is a thermal grease with a thermal conductivity of 2.0W/(m·K), effectively reducing contact thermal resistance between heat sinks and heat sources. It is suitable for applications requiring minimal compression thickness, constant pressure, and easy screen printing to achieve optimal performance.
Thermal Conductivity: 2.0W/(m·K)
Low free isocyanate content (approaching 0)
Long-lasting performance and high reliability
Excellent wetting on contact surfaces, effectively reduces interfacial thermal resistance
Strong weather resistance
Storage Module
Network Communication Equipment
Consumer Electronics
Power Supply
Industrial Control Equipment
Attribute | Value | Test Method |
Color | White | Visual |
Density (g/cc) | 2.8 | ASTM D792 |
Volatile Content (%) | ≤1.0 | @150℃/24h |
Cone penetration (0.1mm)@25℃ | 340 | GB/T269 |
Usage Temperature(°C) | -40~150 | / |
Shelf Life (Month) | 12 | Temperature<40℃ avoid extrusion and exposure to the sun |
Electrical performance | ||
Breakdown Voltage (kV/mm) | ≥4.0 | ASTM D149 |
Thermal conductivity | ||
Thermal Conductivity (W/(m·K)) | 2.0 (Reference) | ISO 22007-2 |
Thermal Resistance (℃·in2/W) | ≤0.06 | ASTM D5470 |
