PCM600 is a high-performance thermal phase change material with a phase change temperature point of 50- 60°C. PCM600 is a solid flake at room temperature and a paste after the phase transition temperature, with excellent wettability and compressibility. It can be cut into various sizes according to customer requirements and attached between the radiator and the power consumption electronics. Fill the gap between the heat source and the radiator to minimize the thermal resistance. The PCM600 offers high thermal conductivity, low thermal resistance and excellent reliability.
High thermal conductivity, low thermal resistance
Thermal conductivity phase change materials
Excellent wettability
Excellent reliability
Communication equipment
Computer
LED
Power converter
Properties | Attribute | Test Method |
Color | Grey | Visual |
Thickness (mm) | 0.25 ~ 1.0 | ASTM D374 |
Density (g/cc) | 2.7 | ASTM D792 |
Phase Change Temperature (°C) | 50 ~ 60 | ASTM D3418 |
Usage Temperature (°C) | -40 ~ 125 | / |
Shelf Life (month) | 12 | Temperature<40℃; avoid compression, exposure to the sun |
Electrical | ||
Breakdown Voltage (kV ) | ≥3.0 | ASTM [email protected] |
Thermal | ||
Thermal Conductivity (W/(m K)) | 6.0 | ASTM D5470 |
Thermal Resistance (℃⋅cm2/W) | ≤0.1 | ASTM D5470 @50psi,0.3mm |
