PCM200 High Performance Phase Change Thermal Conductivity Material

PCM200 is a high-performance thermal phase change material with a phase change temperature point of 50-60°C. PCM200 is a solid flake at room temperature and a paste after the phase transition temperature, with excellent wettability and compressibility. It can be cut into various sizes according to customer requirements and attached between the radiator and the power consumption electronics. Fill the gap between the heat source and the radiator to minimize the thermal resistance. The PCM200 offers high thermal conductivity, low thermal resistance and excellent reliability.

Features:

High thermal conductivity, low thermal resistance

Thermal conductivity phase change materials

Excellent wettability

Excellent reliability

Typical Applications:

Communication equipment

Computer

LED

Power converter

Send Inquiry

Technical Information about PCM200 High performance phase change thermal conductivity material

Properties	Attribute	Test Method
Model	PCM200	/
Color	White	Visual
Thickness(mm)	0.25~1.0	ASTM D374
Density(g/cc)	2.4	ASTM D792
Phase Change Temperature(°C)	50-60	ASTM D3418
Usage Temperature(°C)	-40~125	/
Shelf Life(month)	12	Temperature<40℃ avoid extrusion and exposure to the sun
Electrical
Breakdown voltage(kV)@0.3mm	≥8	ASTM D149
Thermal
Thermal Conductivity (W/m·k)	2.0	ASTM D5470
Thermal Resistance (℃-cm2/W [email protected])	0.53	ASTM D5470
Thermal Resistance (℃-in2/W [email protected])	0.082	ASTM D5470
